The fuse elements from Stadtfeld are suitable for installation in existing as well as new candelabras. Also, Stadtfeld has a socket for uncomplicated mounting on the candelabra.
Fuse element type HSW 1921
Fuse element, complete with fuse heads and fuse cartridges. With 2 fuses, type HSW 1921 - fuse holder with plastic screw caps E14
Order number 104246 / 104296
Fuse 2 x 6 A/D01 / 2 x 10 A/D01
Connection 3L+N+PE
Terminal 5 x 10 mm2
Pole-Ø inside 70 mm
Mass 66 x 264 x 57 mm (WxHxD)
Fuse element type HSW 2320
Fuse element, complete with fuse heads and fuse cartridges. With 2 fuses, type HSW 2320 - fuse holder with porcelain screw caps E14
Order number 104258 / 104247
Fuse 2 x 6 A/D01 / 2 x 10 A/D01
Connection 3L+N+PE
Terminals 5 x 16 mm2
Pole-Ø inside 89 mm
Dimensions 84 x 290 x 72 mm (WxHxD)
Fuse element type HSW 2330
Fuse element, complete with fuse heads and fuse cartridges. With 3 fuses, type HSW 2330 - fuse holder with porcelain screw caps E14
Order number 104253 / -
Fuse 3 x 10 A+D01 / 3 x 16 A/D01
Connection 3L+N+PE
Terminal 5 x 16 mm2
Pole-Ø inside 89 mm
Mass 84 x 265 x 72 mm (WxHxD)
Socket HSW 4021 / 4022 for mounting on candelabra
The sockets HSW 4021 / 4022 are ideal for quick mounting on conical or cylindrical candelabra due to their complete pre-wired design. Consists of an impact-resistant, fiberglass-reinforced and UV-stabilizing polycarbonate and a high-quality pre-assembled connection cable, which is pre-assembled by means of bend protection and strain relief. For mounting, drill a 12 mm hole in the candelabra for cable entry.
Socket type 13/IP 55
Splash-proof (10A / 250 V)
Order number 164399
Socket Type 13 / IP 55 (10 A / 250 V)
Dimensions 86 x 111 x 83 mm (WxHxD)
incl. cable 6.0 m
Socket type 23/IP 55
Splash-proof (16A / 250 V)
Order number 164400
Socket outlet Type 23 / IP 55 (16 A / 250 V)
Dimensions 86 x 111 x 83 mm (WxHxD)
incl. cable 6.0 m
Other interesting products
Fiber optic candelabra
Fiberglass candelabra provide high security & resistance.
Fiberglass is the material for impressive robustness. Thanks to the nature of the material, fiberglass candelabras offer the highest passive safety compared to candelabras made of steel or aluminum. In addition, that has fiberglass the highest corrosion resistance to chemicals and road salts.
Due to the properties of fiberglass, there is full insulation. The fiberglass candelabra are available in all UV-resistant colors.
Steel candelabra
Whip and standing steel candelabra - The popular classics
Steel candelabra are the most common in Switzerland and are thus considered classics in street lighting. The optimal price-performance ratio makes steel the most popular material for candelabra. In addition, steel is also ideal for the manufacture of special solutions. Hot-dip galvanizing protects the surface against corrosion and ensures a long service life.
