Luma gen1 UP

Upgrade instead of replace: The circular, efficient and climate-friendly solution for the Luma gen1 luminaire family

The upgrade kit transforms the Luma gen1 into a future-proof LED luminaire without replacing the aluminum housing. The Ledgine-O technology integrates seamlessly into the original design and offers a complete technical renewal with unchanged optics.

So you can give existing first-generation Luma luminaires a second life.

Technical Data

Zhaga-D4i interface(s)	2x Zhaga 4-Pin (top and bottom)
Module luminous flux	800 – 50’000 lm
Equipement	6 – 200 LED
Light color temperature	2’200K / 2’700K 3’000K / 4’000K
Optics	DN10 / DN11/ DM12
Controls	DynaDimmer, DALI
Controls options	SR / SR-DD / IAC
Protection class	IP66
Color	Gris 150 / Gris 900
Dimensions	48 – 60mm / 76mm

Downloads

Datenblatt Luma gen1 UP Flyer Luma gen1 UP

Lighting control

Eagle Eye Zhaga Radarsensor

Interact City OLC gen2

Multisensor Radarsensor

TrafficDim - verkehrsabhängige Steuerung

Features

Climate-friendly available with CO2 certificate

Ready to give your Luma a second life?

Request a quote now

Throwing away was yesterday

Why it's worth upgrading instead of replacing Learn more here

Conversion in social institutions in Switzerland

Technical details

Lighting type	Light code	A (mm)	B (mm)	Max. wind exposure area SCx(m2)	Weight
Luma gen1 Micro Upgrade	BGP615 Upgrade	551	295	0,049m2	7,5kg
Luma gen1 Mini Upgrade	BGP621 Upgrade	649	295	0,055m2	9,5kg
Luma gen1 Luma 1 Upgrade	BGP623 Upgrade	649	360	0,057m2	11,0kg
Luma gen1 Luma 2 Upgrade	BGP625 Upgrade	799	484	0,066m2	15,5kg

Lighting control

System Ready (SR)	System Ready (SR) + DynaDimmer (DD)	System Ready (SR) + Interact City (IAC)
Light without control (off-on). Light is equipped with 2 Zhaga Book18 interfaces for mounting optional controllers (OLC) and sensors in accordance with the Zhaga D4i standard.	System Ready (SR) luminaire with a self-sufficient, multi-stage programmed night-time reduction function to optimise the lighting level during low-traffic periods and save energy.	System Ready (SR) luminaire with controller (OLC). The luminaires communicate with the Interact City platform via the mobile network. Interact City is an innovative lighting management system for controlling and managing public lighting.

Light distribution curve Standard optics for Luma gen1 Mircro - Luma3

DN10 optics, narrow

DN11 optics, medium pressure

DN12 wide-angle lens

Luma gen1 upgrade light color 2'200K with SR driver

	Module luminous flux	Connected load	Standard optics	Standard optics	Standard optics
Luma gen1 Micro Upgrade	600 – 6’600lm	5.8 – 56W	DN10	DN11	DN12
Luma gen1 Mini Upgrade	600 – 13’000lm	5.9 – 116W	DN10	DN11	DN12
Luma gen1 Luma 1 Upgrade	2’000 – 20’000lm	16 – 158W	DN10	DN11	DN12
Luma gen1 Luma 2/3 Upgrade	8’400 – 46’000lm	63 – 360W	DN10	DN11	DN12

Luma gen1 upgrade light color 2'700K with SR driver

	Module luminous flux	Connected load	Standard optics	Standard optics	Standard optics
Luma gen1 Micro Upgrade	800 – 7’600lm	6.8 – 59W	DN10	DN11	DM12
Luma gen1 Mini Upgrade	800 – 15’000lm	6.8 – 114W	DN10	DN11	DM12
Luma gen1 Luma 1 Upgrade	2’200 – 23’000lm	15.6 – 164W	DN10	DN11	DM12
Luma gen1 Luma 2/3 Upgrade	8’600 – 50’000lm	56 – 350W	DN10	DN11	DM12

Luma gen1 upgrade light color 3'000K with SR driver

	Module luminous flux	Connected load	Standard optics	Standard optics	Standard optics
Luma gen1 Micro Upgrade	800 – 6’000lm	6.2 – 59W	DN10	DN11	DM12
Luma gen1 Mini Upgrade	3’500 – 94000lm	6.2 – 118W	DN10	DN11	DM12
Luma gen1 Luma 1 Upgrade	6’000 – 20’000lm	14 – 166W	DN10	DN11	DM12
Luma gen1 Luma 2/3 Upgrade	13’000 – 50’000lm	50 – 380W	DN10	DN11	DM12

Luma gen1 upgrade light color 4'000K with SR driver

	Module luminous flux	Connected load	Standard optics	Standard optics	Standard optics
Luma gen1 Micro Upgrade	800 – 9’000lm	5.9 – 59W	DN10	DN11	DM12
Luma gen1 Mini Upgrade	800 – 17’000lm	5.9 – 108W	DN10	DN11	DM12
Luma gen1 Luma 1 Upgrade	2’400 – 26’000lm	14.4 – 156W	DN10	DN11	DM12
Luma gen1 Luma 2/3 Upgrade	8’600 – 64’000lm	47 – 375W	DN10	DN11	DM12
